ZOOMLION 1010400046 FLJ-69 Hydraulic Oil Cooler Unit For ZOOMLION Crane

●ZOOMLION 1010400046 Oil Cooler Technical Support

●The 1010400046 Hydraulic Oil Cooler Unit (FLJ-69 / Radiator device / Dispositivo de radiador / Масляный радиатор гидравлический / Enfriador de aceite hidráulico enfriado por aire) is a heavy-duty electric air-cooled heat exchanger assembly engineered for ZOOMLION truck cranes, all-terrain cranes, and crawler cranes.

●Material number 1010400046 is installed on the uppercarriage hydraulic platform adjacent to the hydraulic fluid reservoir. Featuring a high-thermal-conductivity aluminum plate-fin cooling matrix coupled with a 24V DC high-output axial cooling fan and vibration-isolated mounting frame, it continuously extracts and dissipates excessive heat from the crane main hydraulic circuit return lines. By maintaining hydraulic oil temperature within the optimal operating range (45°C to 65°C), it preserves hydraulic fluid viscosity, prevents thermal degradation of synthetic seals, eliminates hydraulic valve spools sticking, and prevents high-temperature cavitation in main hydraulic pumps and winch motors during prolonged heavy-duty hoisting, boom telescoping, and continuous slewing operations in severe ambient conditions.

●Verify oil port thread size, operating voltage, maximum working pressure, cooling capacity (kW), and mounting bracket dimensions prior to order confirmation.

●ZOOMLION 1010400046 Oil Cooler Specifications

Compatibility note: Cataloged in parts directories and parts manuals for ZOOMLION mobile and crawler cranes (including ZOOMLION QY25V, QY30V, QY50V, QY55V, QY55V532.2, QY70V, ZTC250, ZTC300, ZTC500, ZTC800, ZTC1000V, ZTC1000V753, ZAT1500, QUY180, QUY260 series truck cranes and crawler cranes hydraulic cooling systems). Verify machine model and radiator nameplate before ordering.

●ZOOMLION 1010400046 Oil Cooler KMN Advantages

• Part-number matching for genuine ZOOMLION 1010400046 FLJ-69 hydraulic oil radiator unit replacement.
• Application support for ZOOMLION truck cranes, all-terrain cranes, crawler cranes, and rough terrain cranes.
• Quality verification covering cooling core pressure burst testing, electric fan motor endurance, weld seam integrity, and airflow efficiency.
• Professional sourcing for ZOOMLION hydraulic pumps, control valves, hydraulic tanks, filter elements (1010500008), and winch motors.
• Export-standard reinforced wooden crate packaging and international logistics coordination.
