Description
ZOOMLION 1010302788 Winch Valve for RT55 RT100 Rough Terrain Crane
ZOOMLION 1010302788 winch valve, ZOOMLION RT55 winch valve, ZOOMLION RT100 winch valve, rough terrain crane valve, crane winch hydraulic valve, ZOOMLION hydraulic spare parts, RT55 crane spare parts, RT100 crane parts
Technical Support & Application Verification
● The ZOOMLION 1010302788 is identified as a Winch Valve for rough terrain crane hydraulic systems.
● Available parts catalog references associate this material number with the winch hydraulic control assembly.
● The part is listed for ZOOMLION RT55 and RT100 Rough Terrain Crane applications in the available product and catalog records.
● Before installation, compare the material number, valve body, hydraulic ports, mounting arrangement and original hydraulic circuit documentation.
1010302788 Application Match & Product Specifications
● Part Name: Winch Valve
● Material Number / P/N: 1010302788
● Brand: ZOOMLION
● Applicable Equipment: RT55 Rough Terrain Crane
● Additional Application Reference: RT100 Rough Terrain Crane
● System Application: Winch hydraulic control system
● Component Category: Hydraulic valve
Winch Hydraulic Control Support for Rough Terrain Cranes
● The Winch Valve is used within the crane hydraulic system to support hydraulic control of the winch function.
● The 1010302788 material number provides a direct reference for replacement-parts identification and ordering communication.
● Correct matching of the valve body, mounting points and hydraulic connections helps reduce the risk of selecting an incompatible replacement.
● Installation and commissioning should follow the original ZOOMLION service documentation and the applicable hydraulic-system procedures.
