Description
XCMG 860134757 Telescopic Cylinder for QY50K Truck Crane
Application and technical support
● The XCMG 860134757 is a Telescopic Cylinder for the QY50K Truck Crane telescopic boom system.
● The cylinder supports boom extension and retraction during crane lifting operations.
● The material number provides a direct reference for spare-parts identification, maintenance communication and replacement ordering.
● Before installation, compare the material number, cylinder body, mounting points, hydraulic ports and original QY50K service documentation.
860134757 product specifications
● Part Name: Telescopic Cylinder
● Material Number / P/N: 860134757
● Brand: XCMG
● Applicable Model: QY50K Truck Crane
● System Application: Truck crane telescopic boom system
● Component Category: Hydraulic telescopic cylinder
Boom extension and retraction support
● The Telescopic Cylinder provides hydraulic actuation for the QY50K crane boom telescoping function.
● Controlled cylinder movement supports accurate boom extension and retraction during lifting work.
● The 860134757 part number supports efficient communication between maintenance teams, parts buyers and service personnel.
● Correct matching of the cylinder, hydraulic connections and boom installation position supports dependable replacement work.
● Installation, hydraulic testing and commissioning should follow the applicable XCMG QY50K service procedures.
Professional XCMG crane parts support
● Parts matching is based on the XCMG brand, material number and confirmed QY50K Truck Crane application.
● Photos of the original cylinder, identification label, mounting ends and hydraulic ports support accurate application checking.
● The crane model, serial number and boom installation position should be checked before ordering.
Prepare your replacement request
● Provide a clear photo of the original 860134757 Telescopic Cylinder and its identification label.
● Share the QY50K crane serial number and telescopic boom application for verification.
● Include photos of the cylinder body, rod end, base end, mounting points and hydraulic connections.
● Confirm the required quantity and destination country for quotation preparation.
● Request a final check of the material number and QY50K application before placing an order.
