XCMG 803811840 Truck-Mounted Crane 20-Channel Slip Ring Brush Assembly
● XCMG 803811840 Brush Technical Support
● Part number 803811840 (model XGSC-200-20, supplier code 111278) is the genuine 20-channel conductive slip ring electric brush block assembly engineered for XCMG truck-mounted cranes.
● Material number 803811840 installs inside the center rotating swivel joint housing. Utilizing 20 spring-loaded high-conductivity copper-graphite brush blocks contacting rotating copper rings, it provides tangle-free, continuous 360-degree transmission of 24V power, solenoid valve outputs, remote control signals, and safety sensor data between chassis and upper boom superstructure.
● Periodically inspect carbon brush contact surface wear, check spring tension uniformity across all 20 channels, and keep the slip ring chamber dry and free of conductive dust.
● XCMG 803811840 Brush Specifications
| ● Part Name | 803811840 XCMG Truck-Mounted Crane 20-Channel Slip Ring Brush Assembly |
| ● Model / Spec | XGSC-200-20 (Supplier: 111278) |
| ● Channel Configuration | 20-Channel Multi-Circuit Slip Ring Carbon Brush Assembly (导电环20路电刷) |
| ● Mounting Position | Truck-Mounted Crane Center Rotating Swivel Joint / Electrical Slip Ring Housing Assembly |
| ● System Application | XCMG truck-mounted crane 360-degree continuous slewing electrical power and control signal transmission system |
Compatibility note: Applicable to XCMG SQS and SQZ series truck-mounted crane models manufactured by XCMG Truck-Mounted Crane Factory. Verify slip ring mounting diameter, pin connector wire harnesses, and channel circuit numbers prior to replacement.
● XCMG 803811840 Brush Advantages
- 100% genuine factory-standard electrical slip ring brush block matching XCMG model XGSC-200-20 and material number 803811840.
- Premium high-grade copper-graphite brush blocks offering ultra-low electrical contact resistance, minimal electrical noise, and long service lifespan.
- Independent precision spring-loaded brush holders delivering steady, vibration-resistant contact pressure across all 20 electrical circuits.
- High-dielectric insulating bracket structure preventing inter-channel short circuits under high-load crane duty and humid outdoor conditions.
- Full-range supply support for XCMG hydraulic center swivel joints, wiring harnesses, crane control joysticks, remote receivers, and sensors.
