XCMG 803795419 Hoisting Machinery Left-Hand Cable Reel Box
● XCMG 803795419 Reel Box Technical Support
● Part number 803795419 is the genuine left-hand crane cable reel and draw-wire sensor box assembly DX-09FA-L engineered for XCMG hoisting machinery.
● Material number 803795419 installs on the left side of the crane telescopic base boom. Housing a constant-tension spiral spring, multi-turn precision length potentiometer or encoder, and high-flexibility stainless steel measuring cable, it pays out and retracts cable smoothly in synchronization with boom telescoping to provide real-time boom extension distance signals to the crane load moment indicator (LMI) safety system.
● Check measuring wire guide rollers for wear, ensure spring return tension is smooth without binding, and verify enclosure cable gland tightness against water ingress.
● XCMG 803795419 Reel Box Specifications
| ● Part Name | 803795419 XCMG Hoisting Machinery Left-Hand Cable Reel Box |
| ● Model / Spec | DX-09FA-L |
| ● Mounting Position | Crane Telescopic Boom Base Section Left Side Mounting Bracket Assembly |
| ● System Application | XCMG crane safe load indicator boom length measurement, electrical signal transmission, and cable retraction system |
Compatibility note: Applicable to XCMG mobile cranes, truck-mounted cranes, and telescopic boom hoisting machinery equipped with left-hand draw-wire sensor mounts. Verify mounting bolt circle dimensions, sensor electrical connector pinout, and maximum boom extension length prior to installation.
● XCMG 803795419 Reel Box Advantages
- 100% genuine factory-standard cable reel box matching XCMG specification DX-09FA-L and material number 803795419.
- Heavy-duty corrosion-resistant sealed aluminum alloy housing engineered to IP66 standards for harsh outdoor construction environments.
- High-grade tempered scroll spring mechanism delivering consistent retracting torque and reliable long-stroke wire spooling.
- Integrated precision multi-turn wire length sensor delivering linear, low-noise analog/digital measurement signals to the crane safety computer.
- Full-range supply support for XCMG crane pressure sensors, anti-two-block limit switches, load moment displays, and slip ring assemblies.
