Description
XCMG 803691501 Rear Combined Lamp for Crane Applications
XCMG 803691501 Rear Combined Lamp Technical Support
●This rear combined lamp is identified for XCMG crane rear-lighting applications.
●One public product reference specifies a Delphi connector for this lamp assembly.
●Confirm the original lamp marking, connector arrangement, mounting position and machine serial information before quotation.
XCMG 803691501 Rear Combined Lamp Specifications
●Component Name: Rear Combined Lamp
●Material Number: 803691501
●Application: Crane rear lighting
●Connector Reference: Delphi connector
●Public Model Associations: XCR30_S, XCR55, XCR70, XCR90_S and XCR100_U catalog references
Compatibility note: Public catalogs associate this part with several XCMG XCR-series crane references. Verify the machine model, lamp position, connector and original part marking before ordering; do not select a replacement by model name alone.
XCMG 803691501 Rear Combined Lamp KMN Advantages
- Part-number and rear-lamp position matching before quotation.
- Review of connector and mounting configuration.
- Compatibility confirmation using machine model and serial information.
- Professional sourcing for XCMG crane lighting components.
- International procurement and shipping coordination after confirmation.
