XCMG 803545543 Crawler Crane 25T Hoist Load Tension Sensor Assembly
● XCMG 803545543 Tension Sensor Technical Support
● Part number 803545543 (Hirschmann OEM designation KMD-025-111-Na, cross-reference 214863/KD014466) is the genuine 25-ton tensile load cell sensor engineered for XCMG crawler cranes.
● Material number 803545543 is installed at the boom tip fixed sheave anchor or wire rope dead-end wedge socket assembly. It continuously measures hoisting cable tension and converts mechanical strain into high-precision millivolt electrical signals for the Hirschmann LMI computer, preventing crane overload and tipping accidents.
● Check shielded cable routing, waterproof connector seals, and zero-point calibration values during regular crane safe load indicator testing.
● XCMG 803545543 Tension Sensor Specifications
| ● Part Name | 803545543 XCMG Crawler Crane 25T Hoist Load Tension Sensor Assembly |
| ● Model / Spec | HIRSCHMANN KMD-025-111-Na / 25T Load Cell (214863/KD014466) |
| ● Mounting Position | Boom Head Sheave Anchor & Hoist Wire Rope Dead End Rigging Assembly |
| ● System Application | XCMG crawler crane LMI load moment indicator and overload protection system |
Compatibility note: Applicable to XCMG XGC55, XGC75, QUY50, and QUY70 crawler cranes. Verify LMI system controller version and pin dimensions prior to ordering.
● XCMG 803545543 Tension Sensor KMN Advantages
- 100% genuine OEM Hirschmann tension sensor matching XCMG material number 803545543 and KMD-025-111-Na specifications.
- Hermetically sealed stainless steel body rated IP67 offering extreme resistance to moisture, dust, and outdoor climatic fluctuations.
- High-accuracy internal foil strain gauge bridge delivering linear output, minimal creep, and temperature compensation across -30°C to +70°C.
- Heavy-duty aviation circular connectors ensuring noise-immune analog signal transmission to the cab display computer.
- Comprehensive supply support for XCMG crane angle sensors, length sensors, pressure transducers, limit switches, and LMI displays.
